Iscar E45 Indexable & Chamfer End Mill, 0.472" to 0.91" Cut Diam, 3/4" Shank, 311003

Iscar
E45 Indexable & Chamfer End Mill, 0.472" to 0.91" Cut Diam, 3/4" Shank, 311003

Specs
Minimum Cutting Diameter (Decimal Inch):0.4720
Maximum Cutting Diameter (Decimal Inch): 0.9100
Maximum Depth of Cut (Decimal Inch): 0.2200
Compatible Insert Size: SDMT-AD-N
Shank Diameter (Inch): 3/4
Shank Diameter (Decimal Inch): 0.7500
Number Of Inserts Required: 1 (Insert Not Included)
Insert Style: SDMT-AD-N
Insert Holding Method: Screw Clamping
Overall Length (Decimal Inch): 3.9400
Series: IscarMill
Toolholder Style: E45
Functional Length (Decimal Inch): 1.1800
Maximum Body Diameter (Decimal Inch): 0.7500
Maximum RPM: 7000
Tool Application: Milling
Standards: ISO 13399
Head Length (Decimal Inch): 1.1800
Shank Length (Decimal Inch): 2.7600
UNSPSC Code: 23291600
Number Of Flutes: 1
Coolant Through: No
Included Angle Degree: 45
Shank Type: Weldon Flat
Country of Origin: Israel

MPN: 3110003
PKG QTY: 1 PC
