Kennametal 3/4" 3-Flute Indexable End Mill, Coolant Thru, 6139930

Kennametal
Indexable Square-Shoulder End Mill: M4D075L1103W075L110, 3/4" Cut Dia, 11 mm Max Depth of Cut, 3/4" Dia Weldon Flat Shank, Uses (3) LNGU110408SRGE Inserts, Through Coolant, 3.13" OAL, 6139930

Specs
Cutting Diameter (Decimal Inch): 0.7500 in
Cutting Diameter: 3/4
Overall Length (Decimal Inch): 3.1300
Maximum Depth of Cut (mm): 11.00
Shank Type: Weldon Flat    Shank Diameter (Decimal Inch): 0.7500
Shank Diameter (Inch): 3/4
Insert Holding Method: Screw
Tool Material: Steel
Series: Mill 4-11
Lead Angle: 0
Shank Length (Decimal Inch): 2.0300
Shank Length (mm): 51.56
Head Length (Decimal Inch): 1.1
Maximum RPM: 41700
Coolant Hole Diameter (mm): 4.00
Insert Compatibility: LNGU110408SRGE (Inserts Sold Seperately)
UNSPSC Code: 27112803
Product Service Code: 3455
ISO Number: M4D075L1103W075L110
Number Of Flutes: 3
Number Of Cutter Inserts: 3
Coolant Through: Yes
Country of Origin: UNITED STATES

MPN: 6139930
PKG QTY: 1 PC

Location: SUR-STC-352
