Dorian 69106, SNU-322-UEN-DKU25GT Carbide Inserts (10 PCS)
Description
Dorian Tool
SNU-322-UEN-DKU25GT Carbide Inserts
Technical Specs
Style: SNU
Chipbreaker: UEN
Workpiece Material: Cast Iron, Aluminum, Hardened Steel, Non-Ferrous
Corner Radius: .031 inches
Cutting Angle: 90 degree
Cutting Direction: Neutral
Cut Type: General
Diameter: 3/8 inches
Shape: Square
Thickness: 1/8 inches
Rake Type: Negative Rake Angle
Material: Carbide
Grade: DKU25GT
Finish / Coating: Uncoated
Features
First Choice: For General Application of Cast Iron, Hardened Steel, Non-Ferrous, with Small Depth of Cut and Low Feed per Revolution at Medium SFM (Vc), Light interrupted Cut, Wet/Dry Working Condition. UEN, Ground Surface, no Chip Breaker, Negative Rake Angle, Small Honed Cutting Edge, For General Turning Application, Ferrous and non Ferrous Materials, at Small Depth of Cut (ap) and Feed Rate per Revolution (fn).
Grade Description
The DKU25GT uncoated grade with a hard, tough, wear and abrasive resistant substrate. Medium Cutting Speed, for General Turning Application, from Finishing to Roughing. To cut Carbon Steel, Alloy Steel and Stainless Steel at Medium SFM (Vc) for Light interrupted Cut
MPN: 69106
PKG QTY: 10 PCS
