Dorian 50380 MDPNN24-5D Neutral Toolholder for DNM_543 inserts

Dorian Tool
MDPN N Toolholder Style P- 27.5-Deg. Side Cutting Edge Angle for negative 55-Deg. diamond DNM_ inserts

Technical Specs
Brand: Dorian Tool, Tooling Type: Tool Holder, Style: MDPN, Cutting Hand Direction: Left Hand, Shank Size A: 1.5, Shank Size B: 1.5, Dimension E: 2, Dimension F: NA, Overall Length: 6, Gage Insert: DNM_543, Seat Size: IDSN-533, Lock Pin: NL-58, Clamp: CL-12, Clamp Screw: XNS-510, Optional Seat Screw: S-58

MPN: 50380
PKG QTY: 1 PC
